Nintendo continues to rely on the tri-point screws the company has been using to assemble its consoles and handhelds for decades, and on the Switch 2, many are hidden behind stickers that get damaged in the process of removing them to access the screws. The company has never released repair parts or manuals for the original Switch, and there are currently none available for the Switch 2, so you’ll need third-party alternatives to reassemble the console.
Components like the headphone jack, speakers, microphone, and microSD reader on the Switch 2 are easy to remove. As are buttons that are soldered to breakout boards, and the console’s cooling fan that’s held in place by three screws.
But iFixit describes removing the Switch 2’s battery as an “absolute mission” and “just as bad as the original Switch.” Lots of isopropyl alcohol and a “whole set of pry tools” were needed to remove it, and in the process the foam Nintendo glued to the battery was left disintegrated making a future battery swap a difficult and messy endeavor.
The Switch 2’s gamecard reader, which was modular and relatively easy to remove and replace in the original Switch and Switch OLED models, is now soldered to the console’s mainboard as it is on Switch Lite. iFixit also found three different types of thermal paste used in the Switch 2 which in the original Switch would solidify over time making it hard to remove and less effective at preventing the console from overheating.
Even the new Joy-Cons on the Switch 2 are harder to disassemble, which is problematic because the joysticks are using the same potentiometer technology as the original Joy-Cons that rely on a resistive material that can wear away over time. That’s one of the causes of the original Switch’s notorious joystick drift issue and this time around it’s going to be even harder to do repairs or replace the sticks altogether with Hall effect or TMR alternatives.
